| Engine type |
Single cylinder, 4-stroke, air-cooled, direct injection, diesel engine |
| Bore x stroke [mm] |
86x70 |
| Displacement [ml] |
406 |
| Engine speed [rpm] |
3000/3600 |
| Compression ratio |
19:01 |
| Rated output power [KW (Hp)] |
5.7 (7.75)/3000 |
| Rated output power [KW (Hp)] |
6.3 (8.57)/3600 |
| Fuel |
0# or - 10# light diesel oil |
| Fuel tank volume [L (gal.)] |
5.5 (1.21) |
| Fuel consumption rate [g(ml)/KW.h] |
280 (333) |
| Lubrication oil volume [L (gal.)] |
1.65 (0.36) |
| Power-Take-Off |
Crankshaft |
| Starting system |
Recoil or electric |
| Overall dimension (LxWxH) [mm] |
500x475x555 |
| Dry weight [kg (lbs.)] |
48 (105.6) recoil 53 (116.6) electric |
|
