| Suction, discharge port diameter[mm (in)] |
50 (1.97) |
| Discharge capacity [m3/h] |
22 |
| Total head lift [m (ft)] |
26 (85.3) |
| Max suction head [m (ft)] |
8 (26.25) |
| Rotation speed [rpm] |
3600 |
| Priming time [s/4m] |
80 |
| Overall dimension (LxWxH) [mm] |
505x425x540 |
| Dry weight [kg (lbs.)] |
35 (77) |
| Engine model |
SU170F |
| Rated power [KW (Hp)] |
2.8 (3.8) |
| Rated rotation speed [rpm] |
3600 |
| Displacement [ml (cu.in)] |
211 (12.88) |
| Starting system |
Recoil starter/Electric starter |
| Fuel tank capacity [L (gal.)] |
Small tank 2.5 (0.55) |
| Fuel consumption [g(ml)/KW.h] |
285 (339.29) |
|
