Current location:Home - Products Generator - Diesel Generator

  Diesel Generator 5500LDEN Detailed parameter
Rated frequency [Hz] 50            60
Rated voltage [V] 230       120/240
Rated current [A] 18.3      38.3/19.2
Rated output power [KVA] 4.2          4.6
Max output power [KVA] 4.5          5.0
Rated rotation speed [rpm] 3000      3600
DC output 12V8.3A
Power factor [cos] 1
Phase number Single phase
Noise level [dB(A)@7m] 70-74
Overall dimension (LxWxH) [mm ] 950x565x770
Dry weight [kg] 165 (363)
Structure type Silent type
Excitation mode Self-excitation brushless
Engine model SU186FE
Engine type Single cylinder, 4-stroke, air-cooled,
direct injection, diesel engine
Displacemen [ml (cu.in)] 406 (24.78)
Compression ratio 19:1
Rated power [KW (Hp)/rpm] 5.7 (7.64)/3000   6.3 (8.44)/3600
Starting system 12V electric starter
Rotation dircetion (View from flywheel) Clockwise
Fuel 0# (summer) or -10# (winter) light diesel oil
Lube SAE10W30 (above CC grade)
Low oil pressure alert system With
Battery With 12V-32Ah

* Optional:
Three phase/Hour counter/Remote control/ATS
