| Rated frequency [Hz] |
50 60 |
| Rated voltage [V] |
230 120/240 |
| Rated current [A] |
18.3 38.3/19.2 |
| Rated output power [KVA] |
4.2 4.6 |
| Max output power [KVA] |
4.5 5.0 |
| Rated rotation speed [rpm] |
3000 3600 |
| DC output |
12V8.3A |
| Power factor [cos] |
1 |
| Phase number |
Single phase |
| Noise level [dB(A)@7m] |
70-74 |
| Overall dimension (LxWxH) [mm ] |
950x565x770 |
| Dry weight [kg] |
165 (363) |
| Structure type |
Silent type |
| Excitation mode |
Self-excitation brushless |
| Engine model |
SU186FE |
| Engine type |
Single cylinder, 4-stroke, air-cooled,
direct injection, diesel engine |
| Displacemen [ml (cu.in)] |
406 (24.78) |
| Compression ratio |
19:1 |
| Rated power [KW (Hp)/rpm] |
5.7 (7.64)/3000 6.3 (8.44)/3600 |
| Starting system |
12V electric starter |
| Rotation dircetion (View from flywheel) |
Clockwise |
| Fuel |
0# (summer) or -10# (winter) light diesel oil |
| Lube |
SAE10W30 (above CC grade) |
| Low oil pressure alert system |
With |
| Battery |
With 12V-32Ah |
* Optional:
Three phase/Hour counter/Remote control/ATS
|
