| Rated frequency [Hz] |
50 60 |
| Rated power [kw] |
8.0 9.6 |
| Max. power [kw] |
8.8 10.5 |
| Rated voltage [V] |
240.5 |
| Phase number |
Single phase/3 phase |
| Power factor [lag] |
1 |
| Direct current output [V/A] |
12/8.3 |
| Noise level [dB(A)@7m] |
80 |
| Engine model |
SU812D |
| Engine type |
V-twin, 4-stroke, air-cooled, direct injection, diesel engine |
| Displacemen [ml (cu.in)] |
812 |
| Max. power [kw/rpm] |
14.7/3600 11.76/3000 |
| Starting system |
Electric starter |
| Rotation dircetion (View from flywheel) |
Clockwise |
| Fuel |
0# (summer) or -10# (winter) light diesel oil |
| Lube |
SAE10W30 (above CC grade) |
| Low oil pressure alert system |
With |
| Net weight [kg] |
155 |
| Gross weight [kg] |
165 |
| Dimension (LxWxH) [mm] |
850x630x680 |
|
