| Rated frequency [Hz] |
50 60 |
| Rated voltage [V] |
230 240 |
| Rated current [A] |
9.6 10.42 |
| Rated output power [KVA] |
2.2 2.5 |
| Rated rotation speed [rpm] |
3000 3600 |
| Rated welding DC current (A) |
160 |
| Rated welding work voltage (V) |
26 |
| Welding load continuous ratio |
0.4 |
| Current regulation range (A) |
50-180 |
| Power factor [cos] |
1 |
| Phase number |
Single phase |
| Overall dimension (LxWxH) [mm] |
740x500x660 |
| Dry weight [kg (lbs.)] |
102 (224.4) |
| Structure type |
Open-frame type |
| Continuous running time (at rated load) |
12 hours |
| Starting system |
Recoil starter/Electric starter |
| Engine model |
SU186F/E |
| Engine type |
Single cylinder, 4-stroke, air-cooled, direct injection, diesel engine |
| Rated power [KW (Hp)/rpm] |
5.7 (7.75)/3000 6.3 (8.57)/3600 |
| Fuel |
0# (summer) or -10# (winter) light diesel oil |
| Lube |
SAE10W30 (above CC grade) |
| Battery |
With |
|
