Pump features .Engine and motor direct drive .Forged brass cylider .Anodized crankcase .Ceramic plungers .German Parker water seal .Fixed rate chemical injector .Built-in self suction unloader .Pressure adjustable .ln-line water inlet filter .Quick connect outlet
Optional .Over-pressurze prevention jam nut .Thermal relier valve .Adjustable chemical injector .Pressure gauge .Out-returning unloader .Water inlet hose connector
Model |
SU3WZ-1510A |
Bore(mm) |
ф14 |
Stroke(mm) |
10 |
Max.Pressure(PSI/bar) |
3000/210 |
Flow(GPM/L/min) |
2.5/9.5 |
Power |
8HP |
Rpm |
3400 |
Dimension(cm) |
36x28x25 |
|
