Standard features .Performance-approved electromotor .Motor with aluminium casing .Commercial grade direct drive brass cyinder ceramic plungers radial direction pump .8m high-pressure hose .Quick connect nozzles 0°,15°,40°and chemical nozzle .Pressure adjustable .Low pressure detergent injector .Professional trigger gun with safety lock .10-inch pneumatic wheels .ln-line water filer .Convenient hose and gun hook
Optional .Custom-made motor Voltage and Frequency .Thermal relief valve .Adjustable chemical injector .Pressure gauge .Out-returning unloader .Protection box .Water inlet hose connector .Electric wire with plug
Model |
SU-8.7/18M-1 |
SU-18/20M-2 |
SU-18/20M-3 |
SU-8.7/18M-4 |
Pump Model |
SU3WZ-1510A |
SU3WZ-1510A |
SU3WZ-1808A |
SU3WZ-1510A |
Max.Pressure(PS/bar) |
1680/116 |
2600/182 |
1750/120 |
3000/210 |
Flow(GPM/L/min.) |
1.85/7 |
2.1/8.1 |
2.06/7.8 |
2.06/7.8 |
Power |
3.7kw/4kw |
3.7kw/4kw |
3kw |
3.7kw |
Rpm |
1450 |
2800 |
1450 |
2800 |
Dimension(cm) |
72.5x54x54 |
72.5x54x54 |
72.5x54x54 |
72.5x54x54 |
|
