| STANDBY POWER(KVA) |
275 |
| STANDBY POWER(KW) |
220 |
| RATED POWER(KVA) |
222 |
| RATED POWER（KW） |
200 |
| POWER FACTOR |
0.8 |
| OUTPUT VOLTAGE(V) |
400/230 |
| MAXIMUM OUTPUT CURRENT(A) |
360 |
| GENSET DIMENSION(L×W×H)(mm) |
2950×970×1650 |
| WEIGHT(kg) |
3100 |
| ENGINE （CUMMINS) |
| MODEL |
6LTAA8.9G2 |
THE MAXIMUM OUTPUT POWER(kW) |
265 |
| THE NO.OF CYLINDER |
6L |
FUEL CONSUMPTION(g/kw.h) |
62 |
| BORE/STROKE(mm) |
140/152 |
DISPLACEMENT(L) |
14 |
| EXHAUST AIR FLOW(m3/min) |
490 |
COMPRESS AIR FLOW(m3/min) |
25.7 |
| EXHAUST GAS FLOW(m3/min) |
67.1 |
EXHAUST GAS HIGHEST TEMPERATURE(℃) |
455 |
| LUB-OIL PAN CAPACITY(L) |
36.7 |
ING WATER CAPACITY(L) |
63 |
| VOLE FOR START(V) |
24 |
INSTRUMENT FOR ADJUSTING SPEED |
ELECTRONICALLY CONTROLLED |
| NOISE db(A) |
≤100 |
|
|
| ALTERNATOR (LEROY SOMER) |
| MODEL |
LSA46.2L6 |
EXCITATION |
BRUSH-LESS |
| INSULATION CLASS |
H |
VOLTAGE ADJUST RANGE |
≥±6% |
| FROTECTION CLASS |
IP23 |
STEADY STATE VOLTAGE REGULATION |
≤±1% |
| EFFICIENCY |
92.80% |
VOLTAGE CONTROL |
AVR |
|
