| STANDBY POWER(KVA) |
44 |
| STANDBY POWER(KW) |
35 |
| RATED POWER(KVA) |
40 |
| RATED POWER（KW） |
32 |
| POWER FACTOR |
0.8 |
| OUTPUT VOLTAGE(V) |
400/230 |
| GENSET DIMENSION(L×W×H)(mm) |
1794×980×1380 |
| WEIGHT(kg) |
980 |
| ENGINE （CUMMINS) |
| MODEL |
4BT3.9-G2 |
THE MAXIMUM OUTPUT POWER(kW) |
9.5L/H |
| THE NO.OF CYLINDER |
4L |
FUEL CONSUMPTION(g/kw.h) |
3.9 |
| BORE/STROKE(mm) |
102/120 |
DISPLACEMENT(L) |
≤96 |
| EXHAUST AIR FLOW(m3/min) |
135.6 |
COMPRESS AIR FLOW(m3/min) |
4.13 |
| EXHAUST GAS FLOW(m3/min) |
9.96 |
EXHAUST GAS HIGHEST TEMPERATURE(℃) |
475 |
| LUB-OIL PAN CAPACITY(L) |
11 |
ING WATER CAPACITY(L) |
28 |
| VOLE FOR START(V) |
24 |
INSTRUMENT FOR ADJUSTING SPEED |
ELECTRONICALLY CONTROLLED |
| ALTERNATOR (LEROY SOMER) |
| MODEL |
LSA42.243.2S15 |
EXCITATION |
BRUSH-LESS |
| INSULATION CLASS |
H |
VOLTAGE ADJUST RANGE |
≥±6% |
| FROTECTION CLASS |
IP23 |
STEADY STATE VOLTAGE REGULATION |
≤±1% |
| EFFICIENCY |
93.90% |
VOLTAGE CONTROL |
AVR |
|
