| STANDBY POWER（KVA） |
68 |
| STANDBY POWER（KW） |
55 |
| RATED POWER（KVA） |
62 |
| RATED POWER（KW） |
50 |
| POWER FACTOR |
0.8 |
| OUTPUT VOLTAGE（V） |
400/230 |
| MAXIMUM OUTPUT CURRENT（A） |
90 |
| GENSET DIMENSION（L×W×H)（mm） |
1890×650×1400 |
| WEIGHT（kg） |
860 |
| ENGINE （DEUTZ) |
| MODEL |
TD226B-4 |
THE MAXIMUM OUTPUT POWER（kW） |
66 |
| THE NO.OF CYLINDER |
4L |
FUEL CONSUMPTION(g/kw.h) |
210 |
| BORE/STROKE（mm） |
105/120 |
DISPLACEMENT（L） |
4.16 |
| EXHAUST AIR FLOW（m3/min） |
168 |
COMPRESS AIR FLOW（m3/min） |
4.67 |
| EXHAUST GAS FLOW（m3/min） |
9.67 |
EXHAUST GAS HIGHEST TEMPERATURE(℃) |
530 |
| LUB-OIL PAN CAPACITY（L) |
9.75 |
ING WATER CAPACITY(L) |
25 |
| VOLE FOR START（V) |
24 |
INSTRUMENT FOR ADJUSTING SPEED |
MECHANICAL |
| NOISEdb(A) |
≤102 |
|
|
| ALTERNATOR (LEROY SOMER) |
| MODEL |
LSA43.2L65 |
EXCITATION |
BRUSH-LESS |
| INSULATION CLASS |
H |
VOLTAGE ADJUST RANGE |
≥±6% |
| FROTECTION CLASS |
IP23 |
STEADY STATE VOLTAGE REGULATION |
≤±0.5% |
| EFFICIENCY |
90.30% |
VOLTAGE CONTROL |
AVR |
|
