| STANDBY POWER（KVA） |
34 |
| STANDBY POWER（KW） |
28 |
| RATED POWER（KVA） |
31 |
| RATED POWER（KW） |
25 |
| POWER FACTOR |
0.8 |
| OUTPUT VOLTAGE（V） |
400/230 |
| MAXIMUM OUTPUT CURRENT（A） |
45 |
| GENSET DIMENSION（L×W×H)（mm） |
1650×650×1400 |
| WEIGHT（kg） |
710 |
| ENGINE （DEUTZ) |
| MODEL |
D226B-3 |
THE MAXIMUM OUTPUT POWER（KW） |
33 |
| THE NO.OF CYLINDER |
3L |
FUEL CONSUMPTION(g/kw.h) |
220 |
| BORE/STROKE（mm） |
105/120 |
DISPLACEMENT（L） |
3.12 |
| EXHAUST AIR FLOW（m3/min） |
155 |
COMPRESS AIR FLOW（m3/min） |
2.83 |
| EXHAUST GAS FLOW（m3/min） |
6 |
EXHAUST GAS HIGHEST TEMPERATURE(℃) |
470 |
| LUB-OIL PAN CAPACITY（L) |
7.75 |
ING WATER CAPACITY(L) |
17 |
| VOLE FOR START（V) |
24 |
INSTRUMENT FOR ADJUSTING SPEED |
MECHANICAL |
| NOISEdb(A) |
≤102 |
|
|
| ALTERNATOR (LEROY SOMER) |
| MODEL |
LSA43.2S1 |
EXCITATION |
BRUSH-LESS |
| INSULATION CLASS |
H |
VOLTAGE ADJUST RANGE |
≥±6% |
| FROTECTION CLASS |
IP22/IP23 |
STEADY STATE VOLTAGE REGULATION |
≤±0.5% |
| EFFICIENCY |
89% |
VOLTAGE CONTROL |
AVR |
|
