| Model |
HS1105 |
HS1110 |
HS1115 |
HS130 |
HS138 |
| LD1105 |
LD1110 |
LD1115 |
LD130 |
LD138 |
| Type |
Water forced circulation or/& hopper-cooled, 4-stroke, D.I. |
| Bore x stroke [mm] |
105×115 |
110×115 |
115×115 |
118×118 |
122×118 |
| Total displacement(L) |
0.995 |
1.092 |
1.194 |
1.29 |
1.38 |
| Compression ratio |
17 |
17 |
17 |
17 |
17 |
| Rated speed（rpm） |
2000-2200 |
2000-2200 |
2000-2200 |
2200 |
2200 |
| Rated power/speed(kW）(12h) |
11.8-17 |
11.8-17 |
11.8-17 |
17.6 |
18.38 |
| Fuel consumption rate [g(ml)/KW.h] |
≤242 |
≤242 |
≤242 |
≤242 |
≤252 |
| Max. torque(N.m) |
57-90 |
57-90 |
57-90 |
≥85.8 |
≥89.4 |
| Fuel consumption(g/kW.h) |
238-242 |
238-242 |
238-242 |
230-235 |
230-235 |
| Starting method |
hand cranking or electric starting |
| Net weight(kg) |
180-200 |
180-200 |
180-200 |
190-210 |
190-210 |
| Applications |
hand cranking or electric starting |
|
