| Model |
304A Tractor |
| Engine Model |
ZN390T |
| Engine Type |
Double-cylinder, vertical, water-cooled, four-stroke diesel engine |
| RATED POWER[KW(HP)] |
22.05 |
| RATED SPEED(RPM) |
2400 |
| Calibration conditions fuel consumption rate g/kW·h |
≤340 |
| Types |
Front：5.00-15 Wheel：9.5-24 |
| Front-wheel tread mm |
1300 / 970-1270 |
| Rear-wheel tread mm |
1080-1680 |
| Wheelbase mm |
1750 |
| RATED TRACTION FORCE(N) |
5.9 |
| PTO SPEED(rpm) |
540，720 ,1000 |
| Speed km/h |
1.77-26.94 |
| Gearbox few stalls |
(3+1)×2 Or (4+1)×2 |
| GROUND CLEARANCE(MM) |
340 |
| OVERALL Dimensions mm |
3177×1510×1438 |
| MIN.USE WEIGHT kg |
1300 |
|
