| Model |
300A Tractor |
| Engine Model |
TY2102 |
| Engine Type |
Double-cylinder, vertical, water-cooled, four-stroke diesel engine |
| Bore x itinerary mm |
102×105 |
| RATED POWER[KW(HP)] |
22.1 |
| RATED SPEED(RPM) |
2400 |
| Calibration conditions fuel consumption rate g/kW·h |
≤250 |
| Types |
Front：5.00-15 Wheel：11.2-24 |
| Front-wheel tread mm |
1070/1270 |
| Rear-wheel tread mm |
1080-1380 |
| Wheelbase mm |
1535 |
| RATED TRACTION FORCE(N) |
5980 |
| PTO SPEED(rpm) |
540，720 Or 540/720 Or 540/1000 |
| Speed km/h |
1.76-26.96 |
| Gearbox few stalls |
(3+1)×2 Or (4+1)×2 |
| GROUND CLEARANCE(MM) |
340 |
| OVERALL Dimensions mm |
2740×1290×1438 |
| MIN.USE WEIGHT kg |
1190 |
|
