| Model |
254 Tractor |
| Engine Model |
Y385/KM385 |
| Engine Type |
3 cylinder, vertical, water-cooled, 4 stroke |
| Bore x itinerary mm |
100×105/85×90 |
| RATED POWER[KW(HP)] |
18.37 |
| RATED SPEED(RPM) |
2350 |
| Calibration conditions fuel consumption rate g/kW·h |
≤258.4/285 |
| Types |
Front：6.00-16 Rear：9.5-24 |
| Front-wheel tread mm |
1100/1300 |
| Rear-wheel tread mm |
1080-1380 |
| Wheelbase mm |
1645 |
| RATED TRACTION FORCE(N) |
5980 |
| PTO SPEED(rpm) |
540 or 760/1000 |
| Speed km/h |
0.26-26.35 |
| Gearbox few stalls |
Six stalls crawling stalls |
| GROUND CLEARANCE(MM) |
295 |
| OVERALL Dimensions mm |
2946×1290×1438 |
| MIN.USE WEIGHT kg |
1140 |
|
