Current location:Home - Products Tractor - 18~30

  18~30 244B Tractor Detailed parameter
Model 244B  Tractor
Engine Model Y385/KM385
Engine Type 3 cylinder, vertical, water-cooled, 4 stroke
Bore x itinerary mm  100×105/85×90
RATED POWER[KW(HP)] 17.6
RATED SPEED(RPM) 2350
Calibration conditions fuel consumption rate g/kW·h  ≤258.4/275
Types  Front:6.00-16    Rear:9.5-24
Front-wheel tread mm  1050/1250
Rear-wheel tread mm  1080-1380
Wheelbase mm 1560/1644
RATED TRACTION FORCE(N) 5980
PTO SPEED(rpm)  540 or 720/1000
Speed km/h  0.26-26.35
Gearbox few stalls Six stalls crawling stalls
GROUND CLEARANCE(MM) 295
OVERALL Dimensions mm  2946×1290×1438
MIN.USE WEIGHT kg  1140
