| Model |
220 Tractor |
| Engine Model |
TY295KT |
| Engine Type |
Double-cylinder, vertical, water-cooled, four-stroke diesel engine |
| Bore x itinerary mm |
95×100 |
| RATED POWER[KW(HP)] |
16.17 |
| RATED SPEED(RPM) |
2300 |
| Calibration conditions fuel consumption rate g/kW·h |
≤265 |
| Types |
Front：4.00-16 Wheel：8.3-24 |
| Front-wheel tread mm |
970 / 970-1270 |
| Rear-wheel tread mm |
920-1380 |
| Wheelbase mm |
1465 |
| RATED TRACTION FORCE(N) |
4600 |
| PTO SPEED(rpm) |
540，720 Or 540/720 Or 540/1000 |
| Speed km/h |
1.53-29.42 |
| Gearbox few stalls |
(3+1)×2 Or (4+1)×2 |
| GROUND CLEARANCE(MM) |
330 |
| OVERALL Dimensions mm |
2540×1235×1288 |
| MIN.USE WEIGHT kg |
1020 |
|
