Current location:Home - Products Tractor - 18~30

  18~30 184 Tractor Detailed parameter
Model 184  Tractor
Engine Model JD295/LL380
Engine Type Double-cylinder, vertical, water-cooled, four-stroke diesel engine
Bore x itinerary mm 90×100
RATED POWER[KW(HP)] 13.24
RATED SPEED(RPM) 2400
Calibration conditions fuel consumption rate g/kW·h  ≤260
Types Front 6.00-12   Wheel 8.3-24
Front-wheel tread mm 1000
Rear-wheel tread mm 920-1380
Wheelbase mm 1645
RATED TRACTION FORCE(N) 4100
PTO SPEED(rpm) 540/720
Speed km/h 0.23-23.67
Gearbox few stalls  (3+1)×2  Or   (4+1)×2
GROUND CLEARANCE(MM) 275
OVERALL Dimensions mm 2946×1235×1300
MIN.USE WEIGHT kg 1100
