  18~30 180 Tractor Detailed parameter
Model 180  Tractor
Engine Model JD295/LL380
Engine Type Double-cylinder, vertical, water-cooled, four-stroke diesel engine
Bore x itinerary mm  90×100
RATED POWER[KW(HP)]  13.24
RATED SPEED(RPM)  2400
Calibration conditions fuel consumption rate g/kW·h  ≤260
Types  Front:4.00-16    Wheel:8.3-24
Front-wheel tread mm  970 / 970-1270
Rear-wheel tread mm  900-1020
Wheelbase mm 1470/1530
RATED TRACTION FORCE(N)  3500
PTO SPEED(rpm) 540/720
Speed km/h  1.46-28.13
Gearbox few stalls  (3+1)×2  Or   (4+1)×2
GROUND CLEARANCE(MM)  330
OVERALL Dimensions mm 2886/2946×1235×1320
MIN.USE WEIGHT kg 1050
