Model |
180 Tractor |
Engine Model |
JD295/LL380 |
Engine Type |
Double-cylinder, vertical, water-cooled, four-stroke diesel engine |
Bore x itinerary mm |
90×100 |
RATED POWER[KW(HP)] |
13.24 |
RATED SPEED(RPM) |
2400 |
Calibration conditions fuel consumption rate g/kW·h |
≤260 |
Types |
Front:4.00-16 Wheel:8.3-24 |
Front-wheel tread mm |
970 / 970-1270 |
Rear-wheel tread mm |
900-1020 |
Wheelbase mm |
1470/1530 |
RATED TRACTION FORCE(N) |
3500 |
PTO SPEED(rpm) |
540/720 |
Speed km/h |
1.46-28.13 |
Gearbox few stalls |
(3+1)×2 Or (4+1)×2 |
GROUND CLEARANCE(MM) |
330 |
OVERALL Dimensions mm |
2886/2946×1235×1320 |
MIN.USE WEIGHT kg |
1050 |
|
