| Model |
404B Tractor |
| EngineModel |
SL3105BT |
| Engine |
Triplex, vertical, water-cooled, four-stroke diesel engine |
| Bore x itinerary mm |
105X110 |
| RATED POWER[KW(HP)] |
29.4 |
| RATED SPEED(RPM) |
2200 |
| Calibration conditions fuel consumption rate g/kW·h |
≤228 |
| Types |
Front ：7.5-16 Rear ：11.2-28 |
| Front-wheel tread mm |
1300 |
| Rear-wheel tread mm |
1300-1600 |
| Wheelbase mm |
1943 |
| RATED TRACTION FORCE(N) |
10320 |
| PTO SPEED(rpm) |
540/720(1000)Double Speed |
| Speed km/h |
0.3-28.9 |
| Gearbox few stalls |
(3+1)×2 Or (4+1)×2 |
| GROUND CLEARANCE mm |
325 |
| OVERALL Dimensions mm |
3825×1625×2065 |
| MIN.USE WEIGHT kg |
2101 |
|
