| Model |
804 Tractor |
| EngineModel |
R4105IT14 |
| Engine |
Four-cylinder, vertical, water-cooled, four-stroke |
| Bore x itinerary mm |
105X135 |
| RATED POWER[KW(HP)] |
59 |
| RATED SPEED(RPM) |
2300 |
| Calibration conditions fuel consumption rate g/kW·h |
≤239 |
| Types |
Front ：8.3-24 Rear ：14.9-30 |
| Front-wheel tread mm |
1350-1650 |
| Rear-wheel tread mm |
1370-1790 |
| Wheelbase mm |
2236 |
| RATED TRACTION FORCE(N) |
16700 |
| PTO SPEED(rpm) |
720 |
| Speed km/h |
2.37-33.82 |
| Gearbox few stalls |
（3+1）×2 Or （4+1）×2 |
| GROUND CLEARANCE mm |
340 |
| OVERALL Dimensions mm |
4060×1929×2568 |
| MIN.USE WEIGHT kg |
3310 |
|
