  65~85 654B Tractor Detailed parameter
Model 654B  Tractor
EngineModel YTR4105T63
Engine  Four-cylinder, vertical, water-cooled, four-stroke
Bore x itinerary  mm  105X125
RATED POWER[KW(HP)] 48
RATED SPEED(RPM)  2300
Calibration conditions fuel consumption rate g/kW·h  ≤235
Types  Front :8.3-24      Rear :14.9-28
Front-wheel tread mm 1450
Rear-wheel tread mm 1510
Wheelbase mm 2236
RATED TRACTION FORCE(N) 13000
PTO SPEED(rpm)  540,720
Speed km/h 2.37-33.82
Gearbox few stalls  (3+1)×2 Or (4+1)×2
GROUND CLEARANCE mm 340
OVERALL Dimensions mm 4060×1929×2568
MIN.USE WEIGHT kg 3190
