Current location:Home - Products Tractor - 65~85

  65~85 650B Tractor Detailed parameter
Model 650B  Tractor
EngineModel YTR4105T63
Engine Four-cylinder, vertical, water-cooled, four-stroke
Bore x itinerary  mm  105X125
RATED POWER[KW(HP)] 48
RATED SPEED(RPM)  2300
Calibration conditions fuel consumption rate g/kW·h  ≤235
Types  Front :6.50-16    Rear :14.9-28
Front-wheel tread mm 1450
Rear-wheel tread mm 1510
Wheelbase mm 2188
RATED TRACTION FORCE(N) 11000
PTO SPEED(rpm)  540/720(1000)Double Speed
Speed km/h 2.37-33.82
Gearbox few stalls (3+1)X2 Or (4+1)X2
GROUND CLEARANCE mm 430
OVERALL Dimensions mm 4010×1929×2568
MIN.USE WEIGHT kg 2900
