Current location:Home - Products Tractor - 85~100

  85~100 1004A Tractor Detailed parameter
Model 1004A  Tractor
EngineModel 6105
Engine 6 CYLINDER,WATER COOLED'VERTICAL,4 STROKE
Bore x itinerary  mm  105X125
RATED POWER[KW(HP)] 73.5
RATED SPEED(RPM) 2400
Calibration conditions fuel consumption rate g/kW·h  ≤242
Types  Front :11.2-24      Rear :16.9-34
Front-wheel tread mm 1610
Rear-wheel tread mm 1620-2020
Wheelbase mm 2195
RATED TRACTION FORCE(N)  22000
PTO SPEED(rpm) 720
Speed km/h 0.48-36.37
Gearbox few stalls (2+1)×4 Or (2+1)×8
GROUND CLEARANCE(MM) 379
OVERALL Dimensions mm 4396×2038×2810
MIN.USE WEIGHT kg 3740
