Current location:Home - Products Tractor - 85~100

  85~100 854B Tractor Detailed parameter
Model 854B  Tractor
EngineModel 4110
Engine Four-cylinder, vertical, water-cooled, four-stroke
Bore x itinerary  mm  110X128
RATED POWER[KW(HP)]  66.2
RATED SPEED(RPM) 2300
Calibration conditions fuel consumption rate g/kW·h  ≤
Types  Front :11.2-24     Rear :16.9-34/13.6-38
Front-wheel tread mm 1610
Rear-wheel tread mm 1620-2020
Wheelbase mm 2195
RATED TRACTION FORCE(N) 20800
PTO SPEED(rpm)
Speed km/h  0.46-34.85
Gearbox few stalls  (2+1)×4 Or (2+1)×8
GROUND CLEARANCE(MM) 379
OVERALL Dimensions mm  4396×2038×2810
MIN.USE WEIGHT kg
