Model |
1254 Tractor |
Engine Model |
LRC6108T79 |
Engine Type |
6 cylinder, vertical, water-cooled, 4 stroke |
Bore x itinerary mm |
108X135 |
RATED POWER[KW(HP)] |
92 |
RATED SPEED(RPM) |
2400 |
Calibration conditions fuel consumption rate g/kW·h |
≤235 |
Types |
Front:14.9-24 Rear:18.4-38 |
Front-wheel tread mm |
1808-2148(1912) |
Rear-wheel tread mm |
1664-2268(1664) |
Wheelbase mm |
2689 |
RATED TRACTION FORCE(N) |
27000 |
PTO SPEED(rpm) |
720 |
Speed km/h |
2.24-29.32 |
Gearbox few stalls |
(3+1)×4 |
GROUND CLEARANCE(MM) |
475 |
OVERALL Dimensions mm |
4800×2330×2980 |
MIN.USE WEIGHT kg |
4600 |
|
