Current location:Home - Products Tractor - 100~125

  100~125 1204 Tractor Detailed parameter
Model 1204  Tractor
Engine Model LR6108T79
Engine Type 6-cylinder, vertical, water-cooled, four-stroke diesel engine
Bore x Stroke mm  105X125
Rated  Power[KW(HP)] 73.5
Rated Speed (RPM) 2400
Fuel Consumption  g/kW·h  ≤242
Tyres  front:14.9-24      wheel:16.9-38
Front-wheel tread mm 1808-2148(1912)
Rear-wheel tread mm 1656-2156(1656)
Wheelbase mm 2689
Rated Traction Force(N)  24000
PTO Speed(rpm)  720
Speed km/h  2.15-28.15
Gearbox  (3+1)×4
Ground Clearance (mm)  470
Overall Dimension mm  4800×2330×2980
Min. Use Weight kg  4500
