Current location:Home - Products Tractor - 100~125

  100~125 1104 Tractor Detailed parameter
Model 1104  Tractor
Engine Model LR6105T79
Engine Type Double-cylinder, vertical, water-cooled, four-stroke diesel engine
Bore x itinerary mm  105X125
RATED POWER[KW(HP)] 80.9
RATED SPEED(RPM) 2400
Calibration conditions fuel consumption rate g/kW·h  ≤248.9
Types front:14.9-24      wheel:16.9-38
Front-wheel tread mm 1808-2148(1912)
Rear-wheel tread mm 1664-2268(1664)
Wheelbase mm 2689
RATED TRACTION FORCE(N) 24000
PTO SPEED(rpm)  720
Speed km/h 2.15-28.15
Gearbox few stalls  (3+1)×4
GROUND CLEARANCE(MM) 470
OVERALL Dimensions mm 4800×2330×2980
MIN.USE WEIGHT kg 4500
