| Model |
WP-10C2 |
| Suction, discharge port diameter [mm (in)] |
25 (1) |
| Discharge capacity [m3/h] |
7 |
| Max head lift [m] |
22 |
| Max suction head [m] |
8 |
| Rotation speed [rpm] |
6500 |
| Overall dimension (LxWxH) [mm] |
340x300x390 |
| Dry weight [kg] |
10.5 |
| Engine model |
1E40F Air-cooled single-cylinder 2-stroke |
| Power [Hp] |
1.5 |
| Rated rotation speed [rpm] |
6500 |
| Fuel tank capacity [L] |
1.2 |
| Fuel consumption [g/KW.h] |
610 |
|
